How Does Pedestrian Turnstile Work?

Authorization & Instant Opening

When a valid credential is presented, the system verifies the permission and open automatically. The system processes the data in real-time and allow the authosized person without delay.

Intelligent Anti-Tailgating Logic

If the second person attempts to follow the authorized user within a certain distance, it will instantly trigger an audible and visual alarm.The turnstile either remain locked or closed, effectively prventing unauthorized following.

Auto-Reset & Automatic Close

After the authorised person passed, the turnstile closes automatically.If the user does not pass within the preset time, the system will cancel the access permission and closes the wings to prevent misuse and keep the lane ready for the next user.

Continuous Passage in Peak Hours

When multiple authorized users present credentials consecutively, the turnstile opens on the first authentication and stays open until the last authorized person has passed. This significantly boosts throughput, supporting up to 60 persons per minute during rush hours.

Emergency & Fail-Safe Mode

Upon receiving an emergency signal, the turnstile remains open to form an unobstructed evacuation corridor. In case of power failure, the wings automatically release to a free-swinging state – fully compliant with international fire safety codes.

Seamless Integration with Existing Infrastructure

Our LPR and ticketing system integrates effortlessly with existing parking infrastructure, ensuring a quick setup with minimal disruption. It works perfectly for both small parking lots and large multi-level facilities.

Why Choose Pedestrian Turnstile?

Superior Security & Anti-Tailgating

With 12 pairs of infrared sensors and a tailgating detection resolution, the turnstile instantly identifies and alarms any unauthorized following. The anti-crash locking mechanism physically resists forced entry.

Fast & Efficient Throughput

Opening speed as fast as less than 0.5s and continuous passage mode support up to 60 persons per mins – dramatically reducing queues and improving pedestrian experience.

Flexible Integration with Any Access System

Supports dry contact, and RS485 interfaces. Works seamlessly with face recognition terminals, IC/ID card readers, QR scanners, ID card readers, and more – no proprietary lock-in.

Ultra-High Reliability

Rated for more than million operating cycles and above 5 million mean cycles between failures, the turnstile is built for decades of trouble-free use in high-traffic commercial buildings.

Safety-First Design

Anti-crush torque sensing stops and reverses the wings upon contact with an obstacle, preventing injury. Emergency open mode and failsafe poweroff ensure safe evacuation at all times.

Easy Customization

The wing material, wing height, stainless steel finish, and even overall dimensions can be tailored to match your architectural and security requirements.
